• diamond segment
  • Diamond Segment for Granite
  • Granite Segment
  • Granite Segment

Granite Segment

  • Usage cutting Granite
  • Size Customized as your request
  • Material Diamond/Metal powder
  • Bond Cobalt/Copper/Iron

  • Product details
  • parameter

 Diamond Segment for Granite:

1. Feature: Good Sharpness, Smooth Cutting, High Efficiency, Long Working life

2. Application: Used for cutting Granite

3. Size can be produced as request

4. Diamond segment formula can be adjusted according to customer requirements


Product Name Saw blade Diameter(mm) Segment Dimension(mm) Segment Number(pcs) Shape
Diamond Segment for diamond saw blade 300 40x3.2x10(15,20) 21 Normal or according to customer's requirement
350 40x3.2x10(15,20) 24
400 40x3.6x10(15,20) 28
450 40x4.0x10(15,20) 32
400 40x3.6x10(15,20) 28
450 40x4.0x10(15,20) 32
500 40x4.0x10(15,20) 36
550 40x4.6x10(15,20) 40
600 40x4.6x10(15,20) 42
650 40x5.0x10(15,20) 46
700 40x5.0x10(15,20) 50
750 40x5.0x10(15,20) 54
800 40x5.5x10(15,20) 57
850 40x5.5x10(15,20) 58
900 24x7.5x13(15) 64
1000 24x7.5x13(15) 70
1200 24x8.0x13(15) 80
1400 24x8.5x13(15) 92
1600 24x9.5x13(15) 108
1800 24x10x13(15) 120
2000 24x11x13(15) 128
2200 24x11x13(15) 132
2500 24x12.5x13(15) 140
2700 24x12.5x13(15) 140

Other related products:
Laser welding diamond blade               Sintered diamond blade                Sliver welding diamond blade
Product Name Saw blade Diameter(mm) Segment Dimension(mm) Segment Number(pcs) Shape
Diamond Segment for diamond saw blade 300 40x3.2x10(15,20) 21 Normal or according to customer's requirement
350 40x3.2x10(15,20) 24
400 40x3.6x10(15,20) 28
450 40x4.0x10(15,20) 32
400 40x3.6x10(15,20) 28
450 40x4.0x10(15,20) 32
500 40x4.0x10(15,20) 36
550 40x4.6x10(15,20) 40
600 40x4.6x10(15,20) 42
650 40x5.0x10(15,20) 46
700 40x5.0x10(15,20) 50
750 40x5.0x10(15,20) 54
800 40x5.5x10(15,20) 57
850 40x5.5x10(15,20) 58
900 24x7.5x13(15) 64
1000 24x7.5x13(15) 70
1200 24x8.0x13(15) 80
1400 24x8.5x13(15) 92
1600 24x9.5x13(15) 108
1800 24x10x13(15) 120
2000 24x11x13(15) 128
2200 24x11x13(15) 132
2500 24x12.5x13(15) 140
2700 24x12.5x13(15) 140

Inquiry :
